Electrothermal Heating MultiMantle – Pear: 10ml, 25ml, 50ml Capacity – Round: 50ml Capacity Model: HM-200-V-50

$1,150.00 ex GST

Contact Us For Availability Prior To Purchase

Product Description

Multi Mantles EMV Series

  • Polypropylene outer case
  • Replaceable flexible heater cartridge
  • Maximum element temperature 450°C
  • Safety earth (ground) screen for operator safety
  • Integral energy regulator control
  • Flexible heater cartridge. The heating elements are suspended in a thermal insulating former making for quick and simple replacement
  • Safety screen. This earth (ground) screen is preformed in stainless steel and fitted above the heating element. It is earthed (grounded) directly to the supply cable
  • Standard fitments. Incorporates the flexible heater cartridge plus a ‘power’ on indicator lamp, earth screen and internal fuse. With one support clamp. Accepts up to 12.7mm diameter rods

*Other Electrothermal mantles and products are available on request

Catalogue No.

Model

Capacities
Round Flasks to BS2734 (mL)

Diameters
Common 60° Filter Funnels (mm)

Bottom Outlet Diameters (mm)

Wattage/Circuits (W)

Switched Element

HE250-15

EMV0050/CE

Pear: 10,25,50
Round: 50

50, 75, 100

18

1 x 60

No

HE250-20

EMV0250/CE

Round: 100, 150, 250

75, 100

18

1 x 50
1 x 100

Yes

HE250-30

EMV1000/CE

Round: 500, 1000

100, 150, 200

33

1 x 100
1 x 200

Yes

HE250-45

EMV5000/CE

Round: 2000, 3000, 5000

200, 250, 300

68

1 x 300
1 x 500

Yes

With integral, arbitrary scaled, solid state controller. For 230V 50/60Hz a.c. single phase supplies. Without support rod.
